BASIC SETUP
4.3 Simulation Tools
Software simulation functions let you test the soft starter's operation and control circuits without connecting the soft starter to mains
voltage.
• The run simulation simulates a motor starting, running and stopping to confirm that the soft starter and associated
equipment have been installed correctly. Refer to
Run Simulation
on page 27 for details.
• The protection simulation simulates activation of each protection mechanism to confirm that the soft starter and
associated control circuits are responding correctly. Refer to
Protection Simulation
on page 27 for details.
• The output signal simulation simulates output signalling to confirm that outputs and associated control circuits are
operating correctly. Refer to
Output Signal Simulation
on page 28 for details.
The simulations are only available when the soft starter is in Ready state, control voltage is available and the keypad is active.
Access to the simulation tools is protected by the security access code.
The default access code is 0000.
8 | User Manual (710-04840-00M)
