APPENDIX
13. Appendix
13.1 Model code
EMX3-
–
0
2
5
5
–
–
–
Keypad
H = with keypad
X = without keypad
Control voltage
C1 = 110~210 VAC & 220~440 VAC
C2 = 24 VAC/VDC
Mains voltage
V4 = 200~440 VAC
V7 = 380~690 VAC
Bypass
B = internally bypassed
C = non-bypassed (continuous connection)
Nominal current rating
13.2 IEC ratings
Current Ratings for Bypass Operation
80 A : AC-53b 3.5 - 15 : 345
Off time (seconds)
Start time (seconds)
Start current (multiple of motor full load current)
Starter current rating (amperes)
NOTE
Models EMX3-0255C, EMX3-0360C, EMX3-0380C, EMX3-0430C, EMX3-0620C, EMX3-0650C, EMX3-0790C, EMX3-0930C,
EMX3-1200C, EMX3-1410C, EMX3-1600C must be externally bypassed.
In-line connection
AC53b 3.0-10:350
40 ºC <1000 metres
AC53b 3.5-15:345
40 ºC <1000 metres
AC53b 4.0-20:340
40 ºC <1000 metres
AC53b 4.5-30:330
40 ºC <1000 metres
EMX3-0023B
23 A
20 A
17 A
15 A
EMX3-0043B
43 A
37 A
31 A
26 A
EMX3-0050B
50 A
44 A
37 A
30 A
EMX3-0053B
53 A
53 A
46 A
37 A
AC53b 3.0-10:590
40 ºC <1000 metres
AC53b 3.5-15:585
40 ºC <1000 metres
AC53b 4.0-20:580
40 ºC <1000 metres
AC53b 4.5-30:570
40 ºC <1000 metres
EMX3-0076B 76 A 64 A 55 A 47 A
EMX3-0097B 97 A 82 A 69 A 58 A
EMX3-0100B 100 A 88 A 74 A 61 A
EMX3-0105B 105 A 105 A 95 A 78 A
EMX3-0145B 145 A 123 A 106 A 90 A
EMX3-0170B 170 A 145 A 121 A 97 A
EMX3-0200B 200 A 189 A 160 A 134 A
EMX3-0220B
220 A
210 A
178 A
158 A
