APPENDIX
13.7 UL Compliant Installation
This section details additional requirements and configuration settings for the EMX3 to be UL-compliant. Refer to also UL Fuse
Selection and Short Circuit Ratings on page 19.
• Models EMX3-0023B ~ EMX3-0105B
There is no additional requirement for these models.
• Models EMX3-0145B ~ EMX3-0425B, EMX3-0255C ~ EMX3-1600C
Use the recommended pressure terminal/connector kit. Refer to Terminal/Connector Parts on page 87 for more information.
• Models EMX3-0500B ~ EMX3-1000B
These models are UL recognised components. Separate cable landing busbars may be required within the electrical cabinet when
terminating cables sized according to the National Wiring Code (NEC) regulations.
• Terminal/Connector Parts
For models EMX3-0145B~EMX3-0425B and EMX3-0255C~EMX3-1600C to be UL compliant, you must use the recommended
pressure terminal/connector as detailed in the table below.
Models
FLC (A)
No. of wires
Recommended lugs part No.
EMX3-0145B 145 1 OPHD 95-16
EMX3-0170B 170 1 OPHD 120-16
EMX3-0200B
200
1
OPHD 150-16
EMX3-0220B
220
1
OPHD 185-16
EMX3-0255B 255 1 OPHD 240-20
EMX3-0350B 350 1 OPHD 400-16
EMX3-0425B
425
2
OPHD 185-16
EMX3-0255C 255 1 OPHD 240-20
EMX3-0360C 360
2 1 x 600T-2
EMX3-0380C
380
EMX3-0430C 430
EMX3-0620C 620
EMX3-0650C 650
EMX3-0790C
790
4
2 x 600T-2
EMX3-0930C 930 3 2 x 600T-2
EMX3-1200C 1200
4 1 x 750T-4
EMX3-1410C
1410
EMX3-1600C 1600 5
1 x 750T-4
1 x 600T-3
13.8 Disposal Instructions
Equipment containing electrical components may not be disposed of together with domestic waste.
It must be collected separately as electrical and electronic waste according to local and currently
valid legislation.
