PROGRAMMING MENU
9
Motor Data-2
9A Dual Thermal Model Single
9B Motor FLC-2 Model dependent
9C Locked Rotor Time-2 0m:10s
9D Locked Rotor Current-2 600%
9E Motor Service Factor-2 105%
10
Start/Stop Modes-2
10A Start Mode-2 Constant Current
10B Start Ramp-2 0m:10s
10C Initial Current-2 350%
10D Current Limit-2 350%
10E Adaptive Start Profile-2 Constant Acceleration
10F Kickstart Time-2 0000 ms
10G Kickstart Level-2 500%
10H Stop Mode-2 Coast To Stop
10I Stop Time-2 0m:00s
10J Adaptive Stop Profile-2 Constant Deceleration
10K Adaptive Control Gain-2 75%
10L Brake Torque-2 20%
10M Brake Time-2 0m:01s
11
RTD Temperatures
11A RTD/PT100 A °C 50 °C (122 °F)
11B RTD/PT100 B °C 50 °C (122 °F)
11C RTD/PT100 C °C 50 °C (122 °F)
11D RTD/PT100 D °C 50 °C (122 °F)
11E RTD/PT100 E °C 50 °C (122 °F)
11F RTD/PT100 F °C 50 °C (122 °F)
11G RTD/PT100 G °C 50 °C (122 °F)
12
Slip-Ring Motors
12A Motor Data-1 Ramp Single Ramp
12B Motor Data-2 Ramp Single Ramp
12C Changeover Time 150 ms
12D Slip Ring Retard 50%
15
Advanced (Requires Access Code. Default: 0000)
15A Access Code 0000
15B Adjustment Lock Read & Write
15C Emergency Run Disable
15D Shorted SCR Action 3-Phase Control Only
15E Jog Torque 50%
16
Protection Action
16A
Motor Overload
Trip Starter
16B
Excess Start Time
Trip Starter
16C
Undercurrent
Trip Starter
16D Instantaneous Overcurrent Trip Starter
16E Current Imbalance Trip Starter
16F Frequency Trip Starter
16G Input A Trip Trip Starter
16H Input B Trip Trip Starter
16I Motor Thermistor Trip Starter
