PROGRAMMING MENU
NOTE
The access code is not required to use the F1 and F2 buttons. Users can access these functions regardless of the
setting of parameter 15B
Adjustment Lock .
8D – Display A or kW
Options:
Current (default)
Motor kW
Description:
Selects whether the EMX3 will display current (amperes) or motor kilowatts on the main monitoring screen.
8E, 8F, 8G, 8H – User-Programmable Screen
Options:
Blank Displays no data in the selected area, allowing long messages to be shown
without overlapping.
Starter State (default) The starter's operating state (starting, running, stopping or tripped). Only
available for top left and bottom left positions on the screen.
Motor Current
The average current measured on three phases.
Motor pf The motor's power factor, measured by the soft starter.
Mains Frequency The average frequency measured on three phases.
Motor kW
The motor's running power in kilowatts.
Motor HP
The motor's running power in horsepower.
Motor Temp The motor's temperature, calculated by the thermal model.
kWh The number of kilowatt hours the motor has run via the soft starter.
Hours Run The number of hours the motor has run via the soft starter.
Analog Input
The level of analog input A (refer to parameters 6N~6P). This setting is only
available if the input/output expansion option is installed.
Description:
Selects which information will be displayed on the programmable monitoring screen.
• 8E User Screen - Top Left
Default:
Starter State
• 8F User Screen - Top Right
Default:
Blank
• 8G User Screen - Bottom Left
Default:
Hours Run
• 8H User Screen - Bottom Right
Default:
Analog Input
8I – Graph Data
The EMX3 has a real-time performance graph to report the behaviour of critical operating parameters.
Options:
Current (% FLC) (default) Current as a percentage of motor full load current.
Motor Temp (%)
Motor temperature as a percentage of the motor's thermal capacity.
Motor kW (%)
Measured motor kilowatts, as a percentage of maximum kW.
Motor kVA (%) Measured motor kilovolt amperes, as a percentage of maximum kVA.
Motor pf Motor power factor, measured by the soft starter.
Measured motor kW: √3 x average current x mains reference voltage x measured power factor
Maximum motor kW: √3 x motor FLC x mains reference voltage. Power factor is assumed to be 1
Measured motor kVA: √3 x average current x mains reference voltage
Maximum motor kVA:
√3 x motor FLC x mains reference voltage
Description:
Selects which information the graph will display.
8J – Graph Timebase
Options:
10 seconds (default) 10 minutes
30 seconds 30 minutes
1 minute 1 hour
5 minutes
Description:
Sets the graph time scale. The graph will progressively replace the old data with new data.
8K – Graph Maximum
Range:
0% – 600%
Default:
400%
Description:
Adjusts the upper limit of the performance graph.
