APPENDIX
EMX3-0790C 1185 A 1185 A 1075 A 868 A
EMX3-0820B 1230 A 1058 A 910 A 774 A
EMX3-0920B 1380 A 1206 A 1026 A 857 A
EMX3-0930C 1395 A 1395 A 1244 A 992 A
EMX3-1000B
1500 A
1404 A
1194 A
997 A
EMX3-1200C
1800 A
1800 A
1800 A
1606 A
EMX3-1410C
2115 A
2115 A
1979 A
1671 A
EMX3-1600C
2400 A
2400 A
2400 A
2030 A
Current Ratings for Continuous Operation (Not bypassed)
351 A : AC-53a 3.5 - 15 : 50 - 6
Starts per hour
On-load duty cycle (%)
Start time (seconds)
Start current (multiple of motor full load current)
Starter current rating (amperes)
In-line connection
AC53a 3-10:50-6
40 ºC <1000 metres
AC53a 3.5-15:50-6
40 ºC <1000 metres
AC53a 4-20:50-6
40 ºC <1000 metres
AC53a 4.5-30:50-6
40 ºC <1000 metres
EMX3-0255C
255 A
222 A
195 A
171 A
EMX3-0360C
360 A
351 A
303 A
259 A
EMX3-0380C
380 A
380 A
348 A
292 A
EMX3-0430C
430 A
413 A
355 A
301 A
EMX3-0620C
620 A
614 A
515 A
419 A
EMX3-0650C
650 A
629 A
532 A
437 A
EMX3-0790C
790 A
790 A
694 A
567 A
EMX3-0930C
930 A
930 A
800 A
644 A
EMX3-1200C
1200 A
1200 A
1135 A
983 A
EMX3-1410C
1410 A
1355 A
1187 A
1023 A
EMX3-1600C
1600 A
1600 A
1433 A
1227 A
Inside delta connection
AC53a 3-10:50-6
40 ºC <1000 metres
AC53a 3.5-15:50-6
40 ºC <1000 metres
AC53a 4-20:50-6
40 ºC <1000 metres
AC53a 4.5-30:50-6
40 ºC <1000 metres
EMX3-0255C 382 A 334 A 293 A 257 A
EMX3-0360C 540 A 527 A 455 A 388 A
EMX3-0380C 570 A 570 A 522 A 437 A
EMX3-0430C 645 A 620 A 533 A 451 A
EMX3-0620C 930 A 920 A 773 A 628 A
EMX3-0650C 975 A 943 A 798 A 656 A
EMX3-0790C 1185 A 1185 A 1041 A 850 A
EMX3-0930C 1395 A 1395 A 1200 A 966 A
EMX3-1200C 1800 A 1800 A 1702 A 1474 A
EMX3-1410C 2115 A 2033 A 1780 A 1535 A
EMX3-1600C 2400 A 2400 A 2149 A 1840 A
User Manual (710-04840-00M) | 79
