APPENDIX
Inside delta connection
Internally bypassed models
Light
300%, 10 seconds
50 ºC <1000 metres
Standard
350%, 30 seconds
50 ºC <1000 metres
Heavy
450%, 30 seconds
50 ºC <1000 metres
EMX3-0023B 34 A 31 A 24 A
EMX3-0043B 64 A 58 A 43 A
EMX3-0050B 75 A 69 A 52 A
EMX3-0053B
79 A
79 A
67 A
EMX3-0076B
114 A
97 A
69 A
EMX3-0097B
145 A
118 A
87 A
EMX3-0100B
150 A
126 A
97 A
EMX3-0105B
157 A
157 A
118 A
EMX3-0145B
217 A
186 A
135 A
EMX3-0170B
255 A
211 A
165 A
EMX3-0200B
300 A
238 A
202 A
EMX3-0220B
330 A
270 A
234 A
EMX3-0255B
382 A
307 A
270 A
EMX3-0350B
540 A
453 A
360 A
EMX3-0425B
637 A
540 A
453 A
EMX3-0500B
772 A
576 A
486 A
EMX3-0580B
885 A
639 A
540 A
EMX3-0700B
1050 A
772 A
646 A
EMX3-0820B
1230 A
907 A
763 A
EMX3-0920B 1380 A 1009 A 885 A
EMX3-1000B 1500 A 1174 A 1080 A
Non-bypassed models
EMX3-0255C
363 A
330 A
240 A
EMX3-0360C
540 A
453 A
363 A
EMX3-0380C
570 A
511 A
408 A
EMX3-0430C
645 A
540 A
453 A
EMX3-0620C
930 A
739 A
591 A
EMX3-0650C
975 A
772 A
621 A
EMX3-0790C 1185 A 991 A 790 A
EMX3-0930C 1395 A 1126 A 895 A
EMX3-1200C 1800 A 1722 A 1398 A
EMX3-1410C 2115 A 1800 A 1468 A
EMX3-1600C 2400 A 2166 A 1771 A
User Manual (710-04840-00M) | 81
