APPENDIX
Model
A
mm (inch)
B
mm (inch)
C
mm (inch)
D
mm (inch)
E
mm (inch)
F
mm (inch)
Weight
kg (lb)
EMX3-0023B
EMX3-0043B
192 4.2
EMX3-0050B
(7.6) (9.3)
EMX3-0053B
156 124 295 278 n/a
EMX3-0076B
(6.2) (4.9) (11.7) (11.0) 4.5 (9.9)
EMX3-0097B
223 5.0
EMX3-0100B
(8.8) (11.0)
EMX3-0105B
EMX3-0145B
14.0 (30.9)
EMX3-0170B
282 250 438 380 250 n/a 14.2 (31.3)
EMX3-0200B
(11.2) (9.9) (17.3) (15.0) (9.9) 15
EMX3-0220B
(33.1)
EMX3-0255B
26 (57.3)
EMX3-0350B
424 (16.7) 376 (14.9) 440 (17.4) 392 (15.5) 298 (11.8) n/a 29.4
EMX3-0425B
(64.8)
EMX3-0500B
50.0
EMX3-0580B
(110.2)
EMX3-0700B
433 320 640 600 295 n/a 63.5
EMX3-0820B
(17.1) (12.6) (25.2) (23.7) (11.7) (140.0)
EMX3-0920B
64.0
EMX3-1000B
(141.1)
EMX3-0255C
390 (15.4) 320 (12.6) 460 (18.2) 400 (15.8) 279 (11.0) n/a 23 (50.7)
EMX3-0360C
36
EMX3-0380C
(79.4)
EMX3-0430C
430 320 689 522 300 696
EMX3-0620C
(17.0) (12.6) (27.2) (20.6) (11.9) (27.5) 39.5
EMX3-0650C
(87.1)
EMX3-0790C
EMX3-0930C
51.5 (113.5)
EMX3-1200C
574 500 856 727 361 862 128.5 (283.3)
EMX3-1410C
(22.6) (19.7) (33.8) (28.7) (14.3) (34.0) 130 (286.6)
EMX3-1600C
140 (308.6)
NOTE
Dimension C is the height when input and output busbars are at the same end of the unit (top in/top out or bottom
in/bottom out).
For UL compliant installation, input and output busbars must be at opposite ends of the unit. Dimension F applies for
either top in/bottom out or bottom in/top out configuration.
84 | User Manual (710-04840-00M)
