APPENDIX
5C Reset Delay Groups A&B
5D Reset Delay Group C
6
Inputs
6A Input A Function
6B
Input A Name
6C Input A Trip
6D Input A Trip Delay
6E
Input A Initial Delay
6F
Input B Function
6G Input B Name
6H Input B Trip
6I
Input B Trip Delay
6J Input B Initial Delay
6K Input C Function
6L Input D Function
6M
Remote Reset Logic
6N Analog Input Trip
6O Analog Input Scale
6P
Analog Trip Point
6Q
Local/Remote
6R Comms in Remote
7
Outputs
7A Relay A Function
7B Relay A On Delay
7C
Relay A Off Delay
7D Relay B Function
7E Relay B On Delay
7F
Relay B Off Delay
7G
Relay C Function
7H Relay C On Delay
7I Relay C Off Delay
7J
Relay D Function
7K
Relay E Function
7L Relay F Function
7M Low Current Flag
7N
High Current Flag
7O Motor Temperature Flag
7P Analog Output A
7Q
Analog A Scale
7R
Analog A Maximum Adjustment
7S Analog A Minimum Adjustment
7T Analog Output B
7U
Analog B Scale
7V
Analog B Maximum Adjustment
7W Analog B Minimum Adjustment
8
Display
8A Language
8B F1 Button Action
8C
F2 Button Action
8D Display A or kW
8E User Screen - Top Left
