BUSBAR ADJUSTMENT PROCEDURE
If moving the input busbars, the current transformers (CTs) must also be reconfigured.
1. Label the CTs L1, L2 and L3 (L1 is leftmost when looking from the front of the starter). Remove the cable ties and
unscrew the CTs from the bracket.
2. Move the CT bracket to the top of the starter. Position the CTs for the correct phases, then screw the CTs to the
bracket. For models EMX3-0360C ~ EMX3-0930C, the CTs must be placed on an angle (the left hand legs of each
CT will be on the top row of holes and the right hand legs will be on the bottom tabs).
94 | User Manual (710-04840-00M)
