NEMA motor ratings
All ratings are calculated at altitude of 1000 metres and ambient temperature of
50 ºC.
Light
300%, 10 s,
6 starts per hour
Normal
350%, 30 s,
4 starts per hour
Heavy
450%, 30 s,
4 starts per hour
A HP
@240
VAC
HP
@480
VAC
HP
@600
VAC
A HP
@240
VAC
HP
@480
VAC
HP
@600
VAC
A HP
@240
VAC
HP
@480
VAC
HP
@600
VAC
EMX4e-0024B 24 7.5 15 20 17 5 10 15 14 3 10 10
EMX4e-0042B
42
15
30
40
28
10
20
25
22
7.5
15
20
EMX4e-0052B
52
15
30
50
35
10
25
30
28
10
20
25
EMX4e-0064B 64 20 40 60 52 15 40 40 40 10 25 30
EMX4e-0069B 69 25 50 60 59 20 40 50 46 15 30 40
EMX4e-0105B 100 30 75 100 77 25 60 60 52 15 40 50
EMX4e-0115B
115
40
75
100
81
30
60
75
65
20
50
60
EMX4e-0135B
135
50
100
125
99
30
75
100
77
25
60
75
EMX4e-0184B 164 60 125 150 124 40 100 100 96 30 75 75
EMX4e-0200B 200 75 150 200 131 50 100 125 104 40 75 100
EMX4e-0229B
229
75
150
200
156
60
125
150
124
40
100
100
EMX4e-0250B
250
100
200
250
195
75
150
200
156
60
125
150
EMX4e-0352B
341
125
250
350
240
75
200
200
180
60
150
150
EMX4e-0397B 389 150 300 400 261 100 200 250 203 75 150 200
EMX4e-0410B 410 150 300 450 377 150 300 350 302 100 250 300
EMX4e-0550B
550
200
450
500
414
150
350
450
321
125
250
300
EMX4e-0580B
580
200
500
500
477
200
400
500
361
150
300
350
