PROGRAMMABLE PARAMETERS
20F – Motor Connection
Options:
Auto-detect (default)
In-line
Description:
Override the soft starter's motor connection checks, where the
connection is not correctly recognised on a grounded delta
supply.
20G – Shunt Trip Mode
Options:
Disable (default)
Enable
Description:
Reconfigures the soft starter's main contactor output (33, 34) for
use as a shunt trip relay. When the soft starter trips on selected
conditions, the relay will activate and the shunt trip will trigger
the circuit breaker and disconnect mains voltage from the soft
starter.
Use parameters 6C~6T to select which trips will activate the
shunt trip relay.
NOTE
If shunt trip
operation is enabled, the shunt trip relay will activate for certain
non-adjustable trips as well as the selected adjustable trips.
•
Current at Stop
• Current Read Err Lx
• EEPROM fail
• Firing Fail Px
• Instantaneous overcurrent
•
Internal fault
• Motor connection
• SCR Itsm
• VZC Fail Px
9.15 30 Smart Card Parameters
Parameter groups 30 and higher are only visible if a smart card is installed and is
supported by the soft starter. For parameter details, refer to the smart card user
manual.
