SETUP TOOLS
NOTE
If mains voltage is connected, an error
message is shown.
Run Simulation
ATTENTION!
Remove Mains Volts
MENU to Continue
4. Press . The EMX4e simulates starting.
Run Simulation
Starting X:XXs
MENU to Continue
5.
Press . The EMX4e simulates running.
Run Simulation
Running
Apply Stop Signal
6. Apply a stop command from the selected
command source. The EMX4e simulates stopping.
The Run LED flashes.
Run Simulation
Stopping X:XXs
MENU to Continue
7. Press . The Ready LED flashes and the main
contactor relay opens.
Run Simulation
Stopped
MENU to Continue
8.
Press . The EMX4e activates then deactivates
each programmable output.
Run Simulation
Prog Relay A
On
MENU to Continue
9. Press to return to the Setup Tools.
5.4 Load/Save Settings
Load/Save Settings allows users to:
• Reset the EMX4e's parameters to default values
• Load parameter settings from an internal file
• Save the current parameter settings to an internal file
The internal file contains default values until a user file is saved.
To load or save parameter settings:
1. Press
MENU
to open the menu then select Setup
Tools.
2. Scroll to Load/Save Settings and press the
button.
3. Scroll to the required function and press the
button.
Load/Save Settings
Load Defaults
Load User Set
Save User Set
4.
At the confirmation prompt, select YES to confirm
or NO to cancel, then press to proceed.
Load Defaults
No
Yes
