INSTALLATION
1
Three-phase supply
K1
Main contactor
2
Motor
F1
Semiconductor fuses (optional)
3
Control voltage (soft starter)
10, 11 (S1)
Reset
4
Digital inputs
11, 12 (S2)
Start/Stop
5
Motor thermistor input
13, 14
Programmable input A
(default = Input Trip (N/O))
6
Relay outputs
13, 15
Programmable input B
(default = Input Trip (N/O))
7
Analog output B4, B5 Motor thermistor input
8
Control voltage (external
equipment)
33, 34 Main contactor output
9
Pilot lamps
41, 42, 44
Relay output A (default = Run)
10
Communications / Smart
card expansion port
53, 54
Relay output B (default = Run)
21, 22 Analog output
