8 - Defroster Vent/Front Window
❑ Removing and installing, refer to ⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
9 - Defroster Vent/Right Side Window
❑ Removing and installing, refer to ⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
10 - Instrument Panel Vent, Right
❑ Removing and installing instrument panel vents, refer to ⇒ “5.16 Instrument Panel Vents“, page 152 and
⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
2.4 Heater Components
Observe notes for control and regulation of components in heater.
Refer to
⇒ “1.5 Heater Activation and Control Components“, page 3
Note
♦
The air duct in the heater and in the vehicle is the same as on
vehicles with A/C system. Refer to
⇒ “2.13 Air Guide In Evaporator Housing“, page 68 and
⇒ “2.14 Air Guide In Air Distribution Housing“, page 69 .
♦
The heater should be removed and installed the same way as
the A/C unit. Refer to ⇒ “5.3 A/C Unit“, page 108 .
