8 - Defroster Vent/Front Window
❑ Removing and installing, refer to⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
9 - Defroster Vent/Right Side Window
❑ Removing and installing, refer to⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
10 - Instrument Panel Vent, Right
❑ Removing and installing instrument panel vents, refer ⇒ “5.16 Instrument Panel Vents“, page 152 and
⇒ Body Interior; Rep. Gr. 70 ; Removal and Installation .
2.10 Air Flow Door Motor -V71- , Function
with Back Pressure Door Motor Position Sensor -G113-
Note
♦
You can check the adjustment motor's function via the “output
diagnostic test mode“ Vehicle diagnosis, testing and informa‐
tion system -VAS5051B- in the "Guided Fault Finding" or
check it without a tester as follows: if not using a tester, con‐
nect both contacts 5 and 6 on the adjustment motor's connec‐
tor to a 12 volt DC source. The adjustment motor will move in
one direction up until the stop, and will reverse direction if the
plus and minus contacts are switched. Use an adapter cable.
Refer to
⇒ “1.7 Adapter Cable for Activating Control Motors“,
page 30 .
♦
Perform a basic setting on the A/C after installing a new motor.
Refer to Vehicle diagnosis, testing and information system -
VAS5051B- in the "Guided Fault Finding".
♦
Use “output diagnostic test mode“ and “basic setting“ to test
the activation of A/C (heater) electrical components, if neces‐
sary (for example, allocation test) using Vehicle diagnosis,
testing and information system -VAS5051B- in the "Guided
Fault Finding".
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
62 Rep. Gr.87 - Air Conditioning
