3 Specifications
⇒ “3.1 Fastener Tightening Specifications“, page 75
3.1 Fastener Tightening Specifications
Component Fastener Size Nm
Air Intake Grille
3.5
Compressor Drive Plate
Denso Version 1
35
Denso Version 2
30
Sanden Drive Plate
25
Compressor Mounting Bolts
25
Coolant Pipes to Heater Core
2.5
Expansion Valve to Evaporator Bracket
10
Fluid Reservoir On Condenser
10
High Pressure Sensor
8
Oil Drain Plug
Denso
30
Sanden
10
Pressure Relief Valve
Denso
10
Sanden
14.5
Refrigerant Lines to Compressor
25
Refrigerant Lines To Condenser
12
Refrigerant Lines to Expansion Valve
10
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
3. Specifications 75
