13 - Cover For Dust and Pollen Filter
❑ Removing and installing, refer to ⇒ “5.9 Dust and Pollen Filter“, page 138 .
14 - Air Guide Channel To Right Footwell Vent
❑ Different versions. Refer to Electronic Parts Catalog (ETKA).
❑ “Heater“ version (without an opening for installing a temperature sensor).
15 - Plug
❑ Present two times in different version. Refer to
⇒ “2.1 Air Routing and Distribution in Passenger Compartment“, page 44 .
4.3 Air Guide Channel
Note
Remove the heater the same way as removing the A/C unit. The
items that affect components that are only present on the A/C
system are omitted.
– Remove heater. Refer to ⇒ “5.3 A/C Unit“, page 108 .
– Remove electrical attachments from heater. Refer to
⇒ “4.1 Heater Electrical Attachments“, page 18 .
– Disassemble heater as far as necessary. Refer to
⇒ “4.2 Heater“, page 20 .
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
22 Rep. Gr.80 - Heating, Ventilation
