16 - Right Temperature Door Motor -V159-
❑ With Right Temperature Door Potentiometer/Actuator -G221- .
❑ Removing and installing, refer to ⇒ “5.8.6 Right Temperature Door Motor V159 “, page 137 .
Note
17 - Coolant Pipes To Heater Core
18 - Grommet
❑ For sealing any holes in the coolant/refrigerant lines through the plenum chamber bulkhead into the
engine compartment.
19 - Condensation Water Drain Connection
❑ Condensation water drain valve, checking, removing and installing, refer to
⇒ “4.5 Condensation Water Drain Hose, Checking“, page 92 .
20 - Expansion Valve
❑ Refrigerant lines, disconnecting and reconnecting, refer to
⇒ “5.18.13 Refrigerant Lines, Disconnecting and Connecting From Expansion Valve“, page 180 .
❑ Removing and installing, refer to ⇒ “5.18.10 Expansion Valve“, page 174 .
Note
2.3 Refrigerant Circuit Components Over‐
view
Note
♦
Repair work on refrigerant circuit, refer to
⇒ “1.18 Refrigerant Circuit, Repairs“, page 37 .
♦
All work or components marked with
1)
can be repaired, re‐
placed or performed in any workshop (work that does not
pertain to refrigerant circuit).
♦
All parts or work on the refrigerant circuit not identified with
1)
. as well as all refrigerant hoses and refrigerant lines can only
be repaired or replaced in a workshop equipped with the nec‐
essary tools and where the procedures are performed by
qualified personnel (the refrigerant circuit must be dis‐
charged). Refer to ⇒ Refrigerant R134a Servicing; Rep. Gr.
00 ; General Information .
HD = High-pressure end
ND = Low-pressure end
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
2. Description and Operation 49
