Control Module and Fresh Air Blower that are bolted together (each can be replaced separately) will be
introduced as a running change. Refer to
⇒ “1.14 Fresh Air Blower Control Module J126 and Fresh Air Blower V2 “, page 36 and Electronic Parts
Catalog (ETKA).
❑ The Fresh Air Blower Control Module -J126- is installed in the Fresh Air Blower -V2- . Depending on the
version, both of these components can be either replaced separately or only together.
17 - Insulation Mat
18 - Screw Clips
19 - Cable Ties
20 - Wiring Harness Bracket
4.2 Heater
Note
Remove the heater the same way as removing the A/C unit. The
items that affect components that are only present on the A/C
system are omitted.
– Remove heater. Refer to ⇒ “5.3 A/C Unit“, page 108 .
– Remove electrical attachments from heater. Refer to
⇒ “4.1 Heater Electrical Attachments“, page 18 .
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
20 Rep. Gr.80 - Heating, Ventilation
