Note
Various vehicle electrical components (for example, Heated Rear
Window -Z1- and heated seats) that do not belong to the heater
are activated by the Climatronic control module -J255- . Check
the electrical components as described in Guided Fault Finding
(it is the same on both vehicle with and without A/C). Refer to
⇒ “4.4 Components Actuated by A/C System, Electrical Test“,
page 91 and Vehicle diagnosis, testing and information system
-VAS5051B- in the "Guided Fault Finding" function.
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
3. Diagnosis and Testing 17
