testing and information system -VAS5051B- in the "Guided
Fault Finding" function.
– Check coding of Climatronic control module using Vehicle di‐
agnosis, testing and information system -VAS5051B- in the
"Guided Fault Finding" function.
– Check adaptation of Climatronic control module using Vehicle
diagnosis, testing and information system -VAS5051B- in the
"Guided Fault Finding" function..
– Perform A/C system basic setting using Vehicle diagnosis,
testing and information system -VAS5051B- in the "Guided
Fault Finding" function.
Note
♦
Coolant hoses from connections to A/C unit heat exchanger,
removing and installing; refer to
⇒ “5.14 Heater Core“, page 144 .
♦
A/C unit heater core connection in engine coolant circuit. Refer
to⇒ Engine Mechanical; Rep. Gr. 19 ; Description and Oper‐
ation .
♦
Depending on vehicle production period, connection points
may be installed in refrigerant lines on certain versions (not
planned at this time, introduction not yet finalized). Refer to
Electronic Parts Catalog (ETKA). As with connections on var‐
ious components, these connection points may only be loos‐
ened and opened when the refrigerant circuit is empty. Refer
to ⇒ “1.19 Refrigerant Circuit, Servicing“, page 38 and ⇒
Refrigerant R134a Servicing; Rep. Gr. 00 ; Description and
Operation .
♦
Depending on the vehicle production period, a damping cham‐
ber may be installed in the refrigerant lines from the expansion
valve to the compressor on certain versions (not planned at
this time, introduction not yet finalized). Refer to the Electronic
Parts Catalog (ETKA). The damping chamber balances out
pressure fluctuations that can occur when operating the A/C
compressor. Refer to
⇒ “1.19 Refrigerant Circuit, Servicing“, page 38 and ⇒ Re‐
frigerant R134a Servicing; Rep. Gr. 00 ; Description and
Operation .
♦ Component group 1, components outside of passenger com‐
partment, refer to
⇒ “2.6 Components Outside of Passenger Compartment,
Group 1“, page 55
♦ Component group 2, components outside of passenger com‐
partment, refer to
⇒ “2.7 Components Outside of Passenger Compartment,
Group 2“, page 57
Audi TT 2007 ➤
Heating, Ventilation and Air Conditioning - Edition 01.2011
26 Rep. Gr.87 - Air Conditioning
