Audio Technica AT-LP2022 User Manual

Using the product
19
For safety, raise the tonearm by lifting the tonearm lift control lever to the UP position.
Make sure that the power switch is off and the control knob is in the “STOP” position. If the power switch
remains on while the AC adapter is connected, a standby current is always running through the product, even
when it is not being used.
2
Remove the cartridge’s protector.
Pull the protector straight forward to remove it.
If the tonearm is fixed to the tonearm rest, remove the clamp.
3
Place the record on the platter so that the center hole aligns with the spindle.
At 33-1/3 RPM
At 45 RPM
To play a 45 RPM record, attach the 45 RPM adapter.

Audio Technica AT-LP2022 Specifications

General

Cartridge	AT-VM95E
Frequency Response	20-20, 000 Hz
Type	Manual operation
Speeds	33-1/3 RPM, 45 RPM
Stylus	Elliptical
Signal-to-Noise Ratio	50 dB (IEC 98A Weighted)
