Audio Technica AT-LP2022 User Manual

26
Replacing the belt
The belt is a consumable part. Replace the belt if the speed of playback slows down or irregular rotation occurs. As a
rule of thumb, we suggest replacing the belt once a year.
Before replacing the belt, first turn off the power switch, and disconnect the product’s AC adapter from the outlet.
1
Remove the belt from the motor pulley, and then remove the old belt.
2
Attach the new belt to the side of the platter.
3
Attach the drive belt to the motor pulley.
Make sure that the belt does not get twisted.

Audio Technica AT-LP2022 Specifications

General

Cartridge	AT-VM95E
Frequency Response	20-20, 000 Hz
Type	Manual operation
Speeds	33-1/3 RPM, 45 RPM
Stylus	Elliptical
Signal-to-Noise Ratio	50 dB (IEC 98A Weighted)
