Audio Technica AT-LP2022 User Manual

Using the product
21
1
1
Tonearm lift control lever
4
Position the tonearm over the desired location (groove) on the record.
5
Lower the tonearm by moving the tonearm lift control lever to the DOWN position.
Alternatively, you can skip steps 3 and 4, and use your fingers to lift the headshell, move the tonearm over the
desired location on the record, and then place the headshell down to begin playing the record.
Do not subject the product to strong impact during playback.
The tonearm descends slowly onto the record and play begins.
Pausing the record
1
After lowering the volume of the amplifier, etc., sufficiently, lift the tonearm with the tonearm lift
control lever.

Audio Technica AT-LP2022 Specifications

General

Cartridge	AT-VM95E
Frequency Response	20-20, 000 Hz
Type	Manual operation
Speeds	33-1/3 RPM, 45 RPM
Stylus	Elliptical
Signal-to-Noise Ratio	50 dB (IEC 98A Weighted)
