Audio Technica AT-LP2022 User Manual

Part names and functions
8
Rear view
1 12 23 4 5 6
1
Dust cover hinge holders
Attachment points for dust cover hinges.
2
Feet
Adjust the level of the product.
3
Ground (earth) terminal
Connect the amplifier's ground (earth) terminal to this terminal using the RCA audio cable's ground line.
4
Stereo output terminals
Connect the RCA audio cable. Connect it to the amplifier's PHONO input jack. The red terminal is the right channel
and the white terminal is the left channel.
5
Power input jack
Connect the AC adapter.
6
Power switch
Turn on/off the power.

Audio Technica AT-LP2022 Specifications

General

Cartridge	AT-VM95E
Frequency Response	20-20, 000 Hz
Type	Manual operation
Speeds	33-1/3 RPM, 45 RPM
Stylus	Elliptical
Signal-to-Noise Ratio	50 dB (IEC 98A Weighted)
