Livestreaming
16
3
Slide the phantom power switch to the side that matches the type of the microphone connected to
the microphone input jack.
When connecting a condenser microphone, slide the switch to the +48V side.
When connecting a dynamic boom microphone, slide the switch to the OFF side.
For details, refer to "Supplying phantom power to the microphone input jack" (p. 28).
4
Turn on the computer connected to the USB port (USB Type-C, USB2.0).
This product will turn on, and the power indicator lamp (POWER) will light.
Power indicator lamp
5
If you want to play sound on the computer as background music, slide the loopback switch to the
ON side.
For details, refer to "Using the loopback function" (p. 26).
6
Adjust the level control knobs for the microphone and line inputs.
When connecting a microphone to the microphone input jack, turn the microphone input LEVEL to the 12
o’clock position.
When connecting instruments such as a guitar or keyboard to the line input jacks, turn each line input LEVEL
to the 3 o’clock position.
For details, refer to "Adjusting the input level" (p. 24).
To Next Page
