Audio Technica AT-UMX3 User Manual

Livestreaming
19
4
1 2
5
3
1
Electric guitar, electric bass, etc.
2
Electronic keyboard, etc.
3
Smartphone/tablet
4
Microphone
5
Headphones
1
Turn on all the instruments connected to the line input jacks.
2
Slide the line input selector switch to the line input side ( or ) that you want to input.
For details, refer to "Switching the line input" (p. 26).
3
Slide the phantom power switch to the side that matches the type of microphone connected to the
microphone input jack.
When connecting a condenser microphone, slide the switch to the +48V side.
When connecting a dynamic boom microphone, slide the switch to the OFF side.
For details, refer to "Supplying phantom power to the microphone input jack" (p. 28).
