Setting ATW-T3201/ATW-T3202
Setting the gain
1. From the menu screen, press the UP/DOWN button to select
[GAIN], and then press the SET button.
0dB
GAIN
2. Press the UP/DOWN button to select the gain you wish to set.
• The level changes 2dB +/- each time you press the UP/DOWN button.
• It can be set from -10 to +20 dB.
3. Press the SET button.
• The setting is complete.
Setting the RF transmission output
1. From the menu screen, press the UP/DOWN button to select
[RF POWER], and then press the SET button.
2. Press the UP/DOWN button and select [High:30mW],
[Low:10mW] or [Off].
3. Press the SET button.
• The setting is complete.
Setting HPF (High-Pass Filter)
1. From the menu screen, press the UP/DOWN button to select
[HPF], and then press the SET button.
2. Press the UP/DOWN button to select [On] or [Off].
3. Press the SET button.
• The setting is complete.
Setting lock
1. From the menu screen, press the UP/DOWN button to select
[LOCK], and then press the SET button.
Unlock
LOCK
2. Press the UP/DOWN button to select [Lock] or [Unlock].
Lock Locks transmitter buttons
Unlock Unlocks transmitter buttons
3. Press the SET button.
• The setting is complete.
Setting the function for the function button
Select the function to be performed when the function button is
pressed and held.
1. From the menu screen, press the UP/DOWN button to select [Fn
BUTTON], and then press the SET button.
2. Press the UP/DOWN button to select the function you wish to
set.
Disable No function
Mute
(only for ATW-T3202)
Mutes the transmitter
MuteOnLock
(only for ATW-T3202)
Mutes the transmitter (even when transmitter
buttons are locked)
Bkup Freq Switches to backup frequency (When
selected, set the frequency, group, and
channel.)
RF Off Turns off RF transmission output
3. Press the SET button.
• The setting is complete.
High:30mW
RF POWER
O
HPF
Disable
Fn BUTTON

Audio Technica ATW-R3210 Specifications

General

Quantity	1
Antenna type	Removable
Ethernet LAN	No
Mounting type	Rack mount
Product color	Black
Built-in display	Yes
Antennas quantity	2
Antenna connector type	BNC
Operating frequency type	Ultra High Frequency (UHF)
Operating temperature (T-T)	-5 - 45 °C
Total Harmonic Distortion (THD)	1 %
Input voltage	100 - 240 V
Power supply type	AC

Weight and Dimensions

Depth	191 mm
Width	210 mm
Height	43.4 mm
Weight	1100 g
