22
Setting ATW-T3201/ATW-T3202
Setting the mute mode (only for ATW-T3201)
Set the function of the MUTE switch.
1. From the menu screen, press the UP/DOWN button to select
[MUTE MODE], and then press the SET button.
Mute
MUTE MODE
2. Press the UP/DOWN button to select the mode you wish to set.
Mute Mutes the transmitter
MuteOnLock Mutes the transmitter (even when transmitter
buttons are locked)
Disable Disables the MUTE switch
3. Press the SET button.
The setting is complete.
Setting the system-related functions
Setting the battery type
Set the type of batteries used.
The default setting is [Alkaline].
1. From the menu screen, press the UP/DOWN button to select
[UTILITIES], and then press the SET button.
2. Press the UP/DOWN button to select [BATTERY] and press the
SET button.
3. Press the UP/DOWN button to select the battery you wish to set.
Alkaline Select when using alkaline batteries.
NiMH Select when using nickel–metal hydride batteries.
4. Press the SET button.
The setting is complete.
If the appropriate setting is not made for the batteries used, the battery
power indicator will not display the correct information. Always set the
type of battery according to the batteries used.
Setting the indicator
The indicator LED can be turned [On] or [Off].
The default setting is [On].
1. From the menu screen, press the UP/DOWN button to select
[UTILITIES], and then press the SET button.
UTILITIES
2. Press the UP/DOWN button to select [LED] and press the SET
button.
On
LED
3. Press the UP/DOWN button to select [On] or [Off].
4. Press the SET button.
The setting is complete.
Setting the user access level
Set the user access level.
The default setting is [Free].
1. From the menu screen, press the UP/DOWN button to select
[UTILITIES], and then press the SET button.
2. Press the UP/DOWN button to select [ACCESS] and press the SET
button.
3. Press the UP/DOWN button to select [Free] or [UserGroup].
Free No limit
UserGroup Selection of frequency can be made only
from user groups (U1 and U2).
4. Press the SET button.
The setting is complete.
UTILITIES
Alkaline
BATTERY
UTILITIES
Free
ACCESS
