MP-11x & Microsoft Office Communications Server 2007
Quick Installation Guide 10 Document #: LTRT-26301
3 Configuring the MediaPack
The gateway is supplied with the application software residing on its flash memory (set to factory
default parameters).
Note: This guide assumes that the gateway is running firmware version 5.0. If you are
running an earlier version, please update the version to 5.0 (available on
AudioCodes' Web site -- refer to Section 3.3.1.1 on page 17).
3.1 Embedded Web Server Management Tool
The MediaPack gateway contains an embedded HTTP-based server that provides a user-
friendly, client Web interface for gateway configuration and management.
3.1.1 Accessing the Embedded Web Server
The MediaPack's Embedded Web Server is initially accessed using the default IP address
(10.1.10.11), login user name ('Admin'), and login password ('Admin').
Note: Ensure that your MediaPack is in the same subnet as the PC running the Web
browser. If not, refer to Section 3.2 on page 14 for assigning an IP address to
the MediaPack.
¾ To access the Embedded Web Server, take these 4 steps:
1. Open a standard Web-browsing application such as Microsoft™ Internet Explorer™ (Version
6.0 or higher) or Netscape™ Navigator™ (Version 7.2 or higher).
2. In the Web browser's URL address field, enter the IP address of the gateway; the Embedded
Web Server’s ‘Enter Network Password’ screen appears, as shown in the figure below:
Figure 3-1: Enter Network Password Screen
3. Enter the case-sensitive, default username and password. You can later change the login
user name and password, as described in Section 3.1.3 on page 12.
4. Click OK; the Embedded Web Server is accessed, displaying the ‘Quick Setup’ screen.
