Quick Installation Guide 3. Configuring the MediaPack
Version 5.0 33 September 2007
3.3.2.10 Defining DTMF Payload Type
The procedure below describes how to define the dual-tone multi-frequency (DTMF) payload
type. The DTMF payload type used by Mediation Server is 101. You may need to set this value at
the gateway as well.
¾ To define the DTMF payload type, take these 3 steps:
1. Open the ‘DTMF & Dialing’ screen (Protocol Management menu > Protocol Definition >
DTMF & Dialing).
Figure 3-20: DTMF & Dialing Screen
2. Set the 'RFC 2833 Payload Type' field to 101.
3. Click the Submit button to save your changes.
2
