MP-11x & Microsoft Office Communications Server 2007
Quick Installation Guide 16 Document #: LTRT-26301
3.2.3 Assigning an IP Address using HTTP
You can assign an IP address to the gateway using the gateway's Embedded Web Server (based
on HTTP), by connecting the gateway to a PC with a direct, local Ethernet connection.
¾ To assign an IP address to the gateway using HTTP, take these 5 steps:
1. Connect your PC to the gateway by performing the following:
a. Disconnect the gateway from the network and reconnect it to your PC using one of the
following methods:
♦ Use a standard Ethernet cable to connect the network interface on your PC to a
port on a network hub or switch. Use a second standard Ethernet cable to connect
the gateway to another port on the same network hub or switch.
♦ Use an Ethernet cross-over cable to directly connect the network interface on your
PC to the gateway.
b. Change your PC’s IP address and subnet mask to correspond with the gateway's
factory default IP address and subnet mask (listed in Table 3-1).
2. Access the gateway's Embedded Web Server (refer to Section 3.1.1 on page 10); the ‘Quick
Setup’ screen is displayed (Quick Setup menu), as shown in the figure below:
Figure 3-6: Quick Setup Screen
3
3
3
To Next Page
