MP-11x & Microsoft Office Communications Server 2007
Quick Installation Guide 38 Document #: LTRT-26301
5 Monitoring the Gateway
The gateway provides several methods to monitor various operating statuses:
Monitoring the gateway's front-panel chassis LEDs (refer to Section 5.1).
Monitoring the gateway's channels using the Embedded Web Server (refer to Section 5.2 on
page 39).
5.1 Front-Panel LEDs
The gateway provides various operating LEDs on its front-panel, as described in the table below:
Table 5-1: Description of Gateway's Front Panel LEDs
LED Type Color State Definition
Green
On Device powered, self-test OK.
Orange
Blinking Software loading/Initialization.
Ready
Device
Status
Red
On Malfunction.
Green
On Valid 10/100 Base-TX Ethernet connection.
Uplink
Ethernet
Link Status
Red
On No uplink.
Green
On Power is currently being supplied to the gateway.
Power
Power
Supply
Status
--
Off Either there’s a failure / disruption in the AC power
supply or power is currently not being supplied to the
gateway through the AC power supply entry.
Red
On Failure (fatal error) or system initialization.
Fail
Failure
Indication
--
Off No traffic.
Green
On The FXO gateway off-hooks the line towards the PBX.
Green
Blinking Indicates an incoming call, before answering.
Red
On Line malfunction.
Channels
Status
Telephone /
PBX
Interface
--
Off Normal on hook position.
Note: The front panels of the MP-114 and MP-118 are similar except for the number of
Channels Status LEDs.
