Audison bit One HD User Manual

10
USER'S MANUAL
bit One HD /
5. CONNECTIONS
REMOTE TURN ON
1. Through the DRC MP main control switch (to turn on). Keep the DRC MP main control knob pressed (to shut
down). In this case no other Remote In connections are required, but they can coexist
(see section 5.1).
2. By connecting the REMOTE IN terminal with a Remote Out signal coming from an after-market audio source.
3. Through the SPEAKER IN CH1-CH2. The AUTO TURN ON (ART) is activated by connecting the amplied
head unit output to the SPEAKER IN CH1-CH2 input channel. This function can be enabled/disabled using
the bit One HD PC software
(see section 7.4.1).
The bit One HD is on when the Audison logo lights up in blue. After receiving the turn on input the bit One HD takes
6 seconds to start working. It can be turned on / off in the following ways:
5.3 PERSONAL COMPUTER and DIGITAL REMOTE CONTROL (DRC MP)
5.2 HOW TO TURN THE bit One HD ON/OFF
5.1 POWER SUPPLY AND REMOTE TURN ON
WARNING: to power the bit One HD,
use 1 mm
2
(16 AWG) min. cables
POWER SUPPLY
FUSE HOLDER
Not provided
suggested fuse
2A delayed
Ground
Battery
12V
Ground
AMPLIFIERS
DRC IN
DRC / AC Link cable (4,5 m / 177.16”)
USB cable
(powered)
USB INPUT
DRC/ACLink cable (provied)
HOW TO CONNECT THE DRC MP
5
Remote in
Remote in
Remote out
Remote out
