Audison bit One HD User Manual

48
USER'S MANUAL
bit One HD /
The bit One HD software provides a series of equalizers
to be managed on screen which, with extreme versatility,
provide for an optimal calibration of the audio system.
The user can operate on the equalization of the Master
or AUX analog inputs by choosing the “Input EQ” option,
on the whole system equalization by choosing the “Main
EQ” option and on the bit One HD single output channels
equalization by choosing the “Output EQ” option.
1. Input EQ: tick the “Input EQ” box and the equalization curve for the bit One HD active input will be displayed
(see section 9.6). The calibration for the selected analog inputs can be performed with a 5 poles ±12dB equalizer.
2. Main EQ: it displays the bit One HD general output equalization curve. An equalization for all the system’s
outputs can be set up with a 5 poles ±12dB equalizer.
8.9 EQ SETTINGS
8
8

Audison bit One HD Specifications

General

Brand	Audison
Model	bit One HD
Category	Signal Processors
Language	English
