USER'S MANUAL
bit One HD /
10. TECHNICAL SPECIFICATIONS
POWER SUPPLY
Voltage 11÷15 VDC
Operating power supply voltage 7.5 ÷ 14.4VDC
Idling current 0.75 A
Switched off without DRC MP 2 mA
Switched off with DRC MP 5 mA
Remote IN voltage 6.5 ÷ 15 VDC (1mA)
Remote OUT voltage 10 ÷ 15 VDC (130 mA)
ART (Automatic Remote Turn ON) 4÷7 VDC
Fuse 2 A
SIGNAL STAGE
Distortion - THD @ 1 kHz, 1 VRMS Output 0.004 %
Bandwidth @ -3 dB 4.5 Hz ÷ 32k Hz
S/N ratio @ A weighted
Master Input
AUX Input
OPTICAL IN1 / IN2 Inputs
96 dBA
95 dBA
105 dBA
Channel Separation @ 1 kHz 77 dBA
Input sensitivity Pre Master 0.7 ÷ 6.5 V RMS
Input sensitivity Speaker Master 2 ÷ 16 V RMS
Input sensitivity AUX Master 0.3 ÷ 5 V RMS
Input impedance Pre In / Speaker In / AUX 15 kΩ
Max Output Level (RMS) @ 0.1% THD 4 V
INPUT STAGE
Low level (Pre) Ch1÷Ch6, AUX L/R
High Level (Speaker In) Ch1÷Ch12
Digital 2 x Optical (S/PDIF; Max 192 kHz/24 bit)
OUTPUT STAGE
Low level (Pre) Ch1÷Ch13
Digital AD Link 1 Ch1÷Ch8
Digital AD Link 2 Ch9÷Ch13
CONNECTION
From / To Personal Computer 1 x micro USB
To Audison Ampliers 2 x (AC Link/AD LINK) control bus
To Audison DRC MP 1 x AC Link
CROSSOVER
Filter type Full / High Pass / Low Pass / Band Pass
Filter mode and slope
Linkwitz @ 12 / 24 / 36 / 48 dB
Butterworth @ 6 / 12 / 18 / 24 / 30 / 36 / 42 / 48 dB
Bessel @ 6 / 12 / 18 / 24 / 30 / 36 dB
Crossover Frequency 70 steps @ 10 ÷ 20k Hz
Phase control 0° / 180°
EQUALIZER (20 ÷20K Hz)
High Level Inputs (Speaker In) Automatic De-Equalization and Delay compensation
AUX Input Parametric Equalizer: ±12 dB;5 poles
OPTICAL IN1/IN 2 Inputs Parametric Equalizer: ±12 dB;5 poles
OUTPUTS N.13 Parametric Equalizers: ±12 dB;11 poles
MAIN EQ Parametric Equalizer: ±12 dB;5 poles
Dynamic Equalization Self-adjusting System between low and high listening levels
Bass Boost Adjustable parametric pole (±12 dB; 10 ÷ 500 Hz)
TIME ALIGNMENT
Distance 1.4 ÷ 756 cm / 0.6 ÷ 297.7 inches
Delay 0 ÷ 22 ms
Step 0.04 ms, 1.4 cm, 0.6 inch
GENERAL REQUIREMENTS
PC connections USB 1.1 / 2.0 / 3.0 Compatible
Software/PC requirements Microsoft Windows (32/64 bit): XP, Vista, Windows 7, Windows 8, Windows 10
Video Resolution with screen resize min. 800 x 600
Ambient operating temperature range 0 °C to 55 °C (32°F to 131°F)
SIZE
W (Width) x H (Height) x D (Depth) mm/inch 148 x 43.6 x 233 / 5.82” x 1. 7” x 9.17”
Weight kg/lb 1.775 / 3.9
