Autronica AutroGuard V-430 User Manual

Functional Description
Technical Handbook, AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339, Revision 1, 2020-06-29,
Autronica Fire and Security
Page 35
5.9 Protector “Alive Signal”
To indicate that the protector is “alive” (during normal operation), a
red LED blinks periodically. The blinking is configurable (ON/OFF) and
is by default OFF. See configuration, chapter 10.3.1.
When turned ON the LED will give a short blink every time the
protector is communicating with the panel (once every 90 seconds).
5.10 LED Behavior
When the detector is in operation, the following LED behavior
applies:
Protector State
LED State
Description
Off
Default
By default the LED is OFF when the protector is
idle. Alive pulse can be enabled.
Alarm
Steady on
The LED will be steady ON when the detector is
in alarm
Alarm
Fast blinking
60ms/40ms
(ON/OFF)
Alternative behavior of the alarm LED indicator
activated at alarm. Can be configured ON/OFF
as a global option in the configuration tool.
Alive
Blink 100ms (ON)
The alarm LED indicator will blink once every
time it is directly addressed. Can be configured
on/off as a global option in the configuration
tool.
Test
Blinking (ON/OFF)
When the protector is in test state, the LED will
behave as follows:
 1 time every five seconds for a smoke
detector
 2 times every five seconds for a heat
detector
 3 times every five seconds for a
smoke/heat detector
 4 times every five seconds for
smoke/heat/CO detector
(Yellow LED is not yet supported).

Autronica AutroGuard V-430 Specifications

General

Brand	Autronica
Model	AutroGuard V-430
Category	Security Sensors
Language	English
