Autronica AutroGuard V-430 User Manual

Mounting Instructions
Technical Handbook, AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339, Revision 1, 2020-06-29,
Autronica Fire and Security
Page 54
9.3.2 Wire Routing Arrangement Inside Protector Base
The wires must be supported by the cable holders. Make sure that
the wire routing arrangement shown below is used (the arrows point
to the cable holders).
Cable holder
Cable holder
