Autronica AutroMaster ISEMS User Manual

Network Time Protocol
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 55
5.4 Giving AutroMaster Access to Devices
When an installation is completed, only the system administrator (root)
will have access to devices.
A device is a physical file on the harddisk found in the /dev-directory.
All access to computer hardware is possible by reading or writing to a
specific device-file.
An example of a device-file is /dev/ttyS0, which represents serial port
1.
AutroMaster must be given the necessary access to these devices,
which is done in the following way:
 Open a UNIX-window.
 Execute the command chmod_777 followed by the name of the
device.
Depending on the configuration of the system, AutroMaster must be
given access to the following devices.
Device
Explanation
device-file is /dev/ttyS0
Serial Port 1
device-file is /dev/ttyS1
Serial Port 2
device-file is /dev/ttyS4
Serial Port 5 (if installed)
device-file is /dev/ttyS5
Serial Port 6 (if installed)
device-file is /dev/ttyS6
Serial Port 7 (if installed)
device-file is /dev/ttyS7
Serial Port 8 (if installed)
When using our standard PCI serial board no additional software
drivers are needed, but the configuration has to be updated in order to
use the extra serial ports.
 Change the directory:
cd /home/spefun/konfigurasjon
 Edit the file muligelinjer in a text editor, for example:
nedit muligelinjer (or, emacs muligelinjer)
(Other editors to be used can be gedit, kedit, kate, etc.)
 Add the following lines to the file:
/dev/ttyS4
/dev/ttyS5
/dev/ttyS6
/dev/ttyS7
 Save and quit.
_(underscore) is included in the command below to indicate
the space character. Therefore, when typing the command,
use the space key instead of underscore.
