Connections Between Fire Detection Systems and AutroMaster ISEMS
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 72
7. Connections Between Fire
Detection Systems and
AutroMaster ISEMS
7.1 Connections Between AutroMaster and BS-100
One RTZ-20 must be used to convert the signals from RS-232 to 20
mA: current loop. In the panel a BSL-100 must be installed and
configured as channel 2A or 2B.
