Avant e5
77
A. Articulation joint and steering cylinder
B. Front frame
C. Telescopic boom
D. Coupling plate
3. Tyre pressure check
Check tyre pressure when heavy attachments and
extra counterweights are not attached. Correct tyre
pressure depends on intended load. Refer to
Chapter Technical Specifications.
4. Check and tightening of bolts, nuts
and fittings
Check tightness of bolts, nuts and hydraulic fittings
regularly. However, do not overtighten; tighten
hydraulic fittings only if necessary.
Wheel nuts should be tightened 150 Nm.
Check the tightness of the pivot pin locking screws, if
loose tighten and use thread locker.
