Welcome
9
Welcome
Your Avaya 1120E IP Deskphone brings voice and data to your desktop.
The IP Deskphone connects directly to a Local Area Network (LAN)
through an Ethernet connection. You can upgrade the software on your IP
Deskphone to communicate using Session Initiation Protocol (SIP).
In this guide, the labels for programmable keys appear beside the keys
and labels for context-sensitive soft keys appear directly above the keys.
Figure 1 shows the programmable keys and context-sensitive soft keys.
Figure 1: Programmable keys and context-sensitive soft keys
Basic features
Your Avaya 1120E IP Deskphone supports the following features:
• three programmable keys with labels and indicators
• one reserved line key
• four context-sensitive soft keys
• graphical, high-resolution LCD display, backlit, with adjustable
contrast
Programmable
keys
Context-sensitive
soft keys
Line 1 (Reserved)

Avaya 1120E IP Specifications

General

Headset Support	Yes
Speakerphone	Yes
Connectivity	10/100 Mbps Ethernet
Power over Ethernet (PoE)	IEEE 802.3af Class 2
Audio	G.711, G.729a
Protocols	SIP, H.323
Buttons	Programmable buttons
Ethernet Ports	10/100 Mbps
Power Source	PoE or power adapter
