MBOX Studio Hardware Overview 17
MBOX Studio Hardware Overview
MBOX Studio Front Panel
MBOX Studio front panel
MBOX Studio Front Panel
#Item Notes
1 Inputs 1–2 combo XLR/TRS Accepts XLR, 1/4-inch TRS, and 1/4-inch TS
2 Hi-Z Out to Amp Mirrors FX Send 2
3 Headphones 1 and 2 outputs (TRS) and level controls Digital level controls
1 23
