MBOX Control Software Overview
33
Monitor
The Monitor section provides a master volume knob, Mono, Mute, and other parameters that apply to Monitor outputs (only): Main,
Alt/Bluetooth, Headphone 1 and Headphone 2.
Floating Monitor Window
The Monitor section in MBOX Control can be detached from the main screen to become a floating window that can be resized and
placed anywhere on the screen and remains “on top,” to maintain direct access to level, mute, and other monitor parameters even while
working in Pro Tools.
Monitor Section Controls and Indicators
Item Description
Knob Controls output level of the selected mix(es).
LINK Links Main, Alt, Dig, and Bluetooth outputs for linked level control from the Main Monitor Encoder.
MAIN Focuses Monitor controls on Main.
ALT Focuses Monitor controls on Alt.
DIG Focuses Monitor controls on digital outputs (only available when Mirror MAIN to S/PDIF option is selected.).
Bluetooth Focuses Monitor controls on Bluetooth.
MONO Folds the current Monitor output to mono.
MUTE Mutes the current Monitor output(s).
DIM Lowers the current Monitor output(s) by the editable value shown directly below (default is -6 dB, the minimum Dim
amount). Dim can be applied globally (affecting all outputs) or per channel in Preferences.
TALK Unmutes the built-in Talkback mic input.
Detach The upper right corner of the Monitor section provides a Detach icon. Detaches the Monitor Section and turns it into
a floating, “always on top” window. To close the detached Monitor window, click its Detach icon again.
Detaching and moving the Monitor section (shown at left) and floating above Pro Tools before and after resizing (shown at right)
