MBOX Studio Hardware Overview
19
MBOX Studio Back Panel
MBOX Studio back panel
MBOX Studio Back Panel
#Item
19 Power switch
20 USB
21
MIDI IN / OUT
22 MONITOR OUTS (ALT and MAIN)
23
FX LOOPS
24 LINE IN Inputs 5-6
25
MIC/LINE IN 3-4 combo inputs
26 Power input
27
OPTICAL IN / OUT
28 Coax S/PDIF IN / OUT
29 EXP/SW footswitch inputs
30 Kensington Lock
19
26
20 21 22 23 24 25
27 28 29 30
