Appendix A: Specifications 67
Appendix A: Specifications
Avid MBOX Studio
Analog I/O
Input Specifications
Output Specifications
MBOX Studio Input Specifications
Input
Channel
Type
Max Input Level
minimum dBu
Gain
Range
(dB)
THD %
Dynamic
Range
(dB)
EIN dBu
A-wt
Frequency Response
+/- dB
1,2,3,4 Mic 14 60 0.001 112 -129 20 Hz–20 kHz, ±0.125 dB
1,2,3,4 Line 14 60 0.001 112 na 20 Hz–20 kHz, ±0.125 dB
1,2 Inst 14 60 0.004 108 na 20 Hz–20 kHz, ±0.125 dB
5,6 Line 8 na 0.002 112 na 20 Hz–20 kHz, ±0.125 dB
7,8 FX 8 na 0.002 112 na 20 Hz–20 kHz, ±0.125 dB
MBOX Studio Output Specifications
Output Channel
Max Output
dBu min
THD % Dynamic Range (dB)
Frequency
Response
+/- dB
Power into 32
ohm min mW
MAIN_L 19 0.0012 110 0.125
MAIN_R 19 0.0012 110 0.125
ALT_1 19 0.0012 110 0.125
ALT_2 19 0.0012 110 0.125
FX_SEND_1 19 0.0012 110 0.125
FX_SEND_2 18.8 0.002 107.5 0.125
Re-Amp 0 0.002 103 0.3
HP 1,2 na na 102 0.2 120
