Example Audio Connections
Connect equipment to MBOX Studio as suggested in the following diagrams.
Example Front Panel Audio Connections
That’s a lot of gear!
8-channel ADAT Mic Pre
Optical
S/PDIF
Multi-FX, digital
monitors, or other
ABCD
Vocal and guitar
Guitar Re-amplification
Vocal and guitar
