Pro Tools | MTRX Studio Installation Guide12
Connecting Pro Tools | MTRX Studio to Pro Tools | HDX
You can use up to 64 channels of analog and digital I/O with MTRX Studio connected to an HDX card us-
ing two DigiLink Mini cables (not included).
To connect MTRX Studio to an HDX card:
1 Connect the first MTRX Studio DigiLink Mini Port to DigiLink Mini Port 1 on the HDX card using a
DigiLink Mini cable (not included).
2 Connect the second MTRX Studio DigiLink Mini Port to DigiLink Mini Port 2 on the HDX card using
a second DigiLink Mini cable (not included).
+
Figure 1. MTRX Studio connected to both DigiLink Mini ports on an HDX card
