Chapter 5: Additional Operational Information 45
Chapter 5: Additional Operational
Information
Front Panel
Generator/Parameter
Controls
This section details the parameters available from
the multi-function Set, Down, Up and
Run/Stop/Clear/Esc switches on the SYNC HD
front panel. For details on the multi-function Gen-
erator/Parameter switches on the front panel, see
“Front Panel Generator/Parameter Switches” on
page 24.
Parameters
SYNC HD parameters are selected and edited us-
ing the four Generator/Parameter switches.
To select SYNC HD front panel parameters:
1 Press Set.
2 Use the Up and Down switches to scroll through
available parameters, described below.
The 7-segment LEDs in the Generator/Parameter
Display abbreviate some parameter names using
numerals to represent letters (such as “5” to repre-
sent “S” or “s”). The following table identifies
each of these abbreviations.
SYNC HD front panel display of parameters
LED Parameter
SE7 6En Set Generator Start Time
dI6 rEF Digital Reference
SPL FrEC Sample Freq (Rate)
PuLL r7E 1 Pull Up/Down 0.1%
PuLL r7E4 Pull Up 4.167%, Down 4.0%
bASE CLOC External Clock Out
VI7C InS VITC Insertion
rdr LInE (VITC) Reader Line
6En LInE (VITC) Generate Line
burn EnA Window Burn On/Off
FrEE LEn Freewheel Duration
L7C
LEUL/GAIn
LTC Output level/gain
SErVo Gn LTC Servo gain
PICH HLd Pitch Hold On/Off
bIPH PPF Bi-Phase Pulse-per-frame
bIPH SI6 Bi-Phase Signal Configuration
VIdEO SY Video Format (NTSC/PAL)
